В данной теме обсуждаются CPU линейки AMD Ryzen 3X00 (микроархитектура ZEN2)!

Статистика разгона Zen 2 систем >> https://docs.google.com/spreadsheets/d/ ... sp=sharing

Для запуска процессоров 3X00 требуется биос с поддержкой AM4 Combo PI 0.0.7.2A - обновляйте заранее перед установкой процессора самостоятельно или в сервисном центре.

Возьмите себе за правило, с каждым биосом переустаналивать чипсет драйвера. Технология CPPC2 довольно требовательная к согласованию работы Windows и BIOS. Ввиду того что экосистема BIOS не способна подстроиться под Windows - это нужно делать вручную путем деинсталляции чипсета драйвера и установки с каждым обновлением SMU.

ClockTuner for Ryzen(CTR) 1.1 >> https://www.overclockers.ua/cpu/clocktu ... ryzen-1-1/
ClockTuner for Ryzen(CTR) гайд >> https://www.overclockers.ua/cpu/clocktuner-for-ryzen/
ClockTuner for Ryzen(CTR) скачать >> https://www.guru3d.com/files-details/cl ... nload.html

Ссылка 1 -> Процессоры AMD Ryzen 1000-й серии (Summit Ridge\Zen\14nm\AM4)
Ссылка 2 -> Процессоры AMD Ryzen 2000-й серии (Pinnacle Ridge\Zen+\12nm\AM4)
Ссылка 3 -> APU и Athlon линеек AMD «Bristol Ridge» & «Raven Ridge» (Socket AM4)
Ссылка 4 -> Выбор и обсуждение материнских плат AMD Socket AM4 (Matisse, Picasso, Summit Ridge, Raven Ridge, Pinnacle Ridge и Bristol Ridge)
Ссылка 5 -> Выбор оперативной памяти DDR-4
Ссылка 6 -> Выбор материнской платы под процессоры AMD Socket TR4 (Threadripper) и обсуждение особенностей разгона
Обсуждение разгона ОЗУ -> Статистика разгона памяти DDR-4 на платформах AMD (AM4, TR4). Обсуждение результатов. Советы.
FAQ -> Процессоры AMD Ryzen 3000-й серии (Matisse\Zen2\7nm\AM4) #16365973

Модифицированный профиль питания >> https://www.techpowerup.com/review/1usm ... rocessors/




Спецификации
Вложение:
matisse.jpg [ 125.69 КБ | Просмотров: 2390692 ]
[
Обзоры
https://www.youtube.com/watch?v=LCdA-bLRAfM- обзор от Olegdjus
https://www.overclockers.ua/cpu/amd-zen-2-ryzen-7-3700x/ - обзор 3700Х от 1usmus
https://www.overclockers.ua/cpu/amd-ryzen-9-3900x/ - обзор 3900Х от 1usmus
Полезный софт:
AMD Ryzen Master
HCI 6.1
RTC 1.05
HCI Laucher
WinTimerTester 1.1
GSAT - Google stressapp test
LinX v0.7.0 от elesin38
CPU-Z
HWiNFO - Hardware Information, Analysis and Monitoring Tools
TM 5 0.12
TM 5 0.12 1usmus V3 config
RunMemTest Pro v2.5
Prime95
ASUS ZenStates 0.2.2 (только для плат Asus на AM4)


Убедительная просьба, прячьте все (любые) картинки и видео под спойлер - [spoiler=][/spoilеr], не используйте тэг [spoilеr][/spoilеr] без знака "равно" для картинок - он для текста! Уважайте друг друга! Не у всех Интернет безлимитный и многие смотрят эту тему через телефон.

Флуд и оффтоп даже под тэгом /офф или /спойлер - награждается ЖК, как и ответы на сообщения, его содержащие. Краткие правила темы. Увидели сообщение, нарушающее правила - просто жмите СК: отвечать на такие посты не нужно!

_________________
Twitter -> @1usmus

Последний раз редактировалось 1usmus 07.11.2019 0:15, всего редактировалось 14 раз(а).

Реклама

Партнер
  lameover

Member
Статус: Не в сети
Регистрация: 31.01.2019
Откуда: Москва
dev Все лгут© Доктор Хаус

Добавлено спустя 5 часов 35 минут 7 секунд:
Доброго времени суток!
Происходит такая штука, называется WHEA-Logger, событие 17:

Код:
Произошла устранимая ошибка оборудования.

Компонент: PCI Express Endpoint
Источник ошибки: Advanced Error Reporting (PCI Express)

Нотация "шина:устройство:функция" основного устройства: 0x2D:0x0:0x1
Нотация "шина:устройство:функция" дополнительного устройства: 0x0:0x0:0x0
Имя основного устройства:PCI\VEN_10DE&DEV_10F9&SUBSYS_37311462&REV_A1
Имя дополнительного устройства:


ах да, пардон, это в журнале винды, в разделе Система :)

_________________
Ryzen 7 3700x+AMD Prism; MSI X570 Gaming Plus; Ballistix(BLS2K8G4D30AESEK) 2x8@3600MHz; MSI RTX2070 SUPER Ventus stock.

  1usmus

Advanced member
Статус: Не в сети
Регистрация: 07.06.2017
Откуда: Persey omicron
BesInc писал(а):

вот так дела...
человек купил новый проц а видяха стала медленнее работать от этого?


у нас просто тут несколько липовых владельцев, которым скучно и хочется народ загрузить несуществующей проблемой

Добавлено спустя 3 минуты 40 секунд:
lameover
30 числа выйдет фикс на WHEA ,Destiny и на завышенное напряжение во время бездействия системы

Добавлено спустя 4 минуты 38 секунд:
Neery писал(а):
Благодарю за дельный совет, надо ещё время потестить стабильность, но, кажется, помогло. Привык к SOC 1,075 для ZEN 1, у меня лучше всего работало с такой напругой. А тут с 3700x и так было почти 1.09 на авто. Пока не дошёл до 1.137 были проблемы со звуком. Не знаете часом какие границы лучше не превышать для ZEN 2?


1.1 достаточно для худшего контроллера памяти при частоте в 1900мгц
проблема с звуковой картой? - ставим дрова что виндовс хочет , а если не помогло - с сайта МП

_________________
Twitter -> @1usmus

  Jacques

Member
Статус: Не в сети
Регистрация: 11.11.2011
1usmus

медерация вообще работает? или все скатывается в полную помойку
  lameover

Member
Статус: Не в сети
Регистрация: 31.01.2019
Откуда: Москва
1usmus писал(а):
30 числа выйдет фикс на WHEA ,Destiny и на завышенное напряжение во время бездействия системы

Да, я ещё вчера на реддите прочёл. Слежу за темой.
1usmus писал(а):
у нас просто тут несколько липовых владельцев, которым скучно и хочется народ загрузить несуществующей проблемой

Проблема реально была, и как я там где-то выше написал, решилась DDU и установкой последних дров. Видимо при переезде с интела на амд, что-то не очень взлетело.
DOaG писал(а):
Уффф. А я то думал, чего это я 1.48В при простое вижу. Ждёмс.

некоторые отыскивают какие-то интересные способы, после которых у них вольтаж до 0.9 опускается и гигагерцы до 2.2

_________________
Ryzen 7 3700x+AMD Prism; MSI X570 Gaming Plus; Ballistix(BLS2K8G4D30AESEK) 2x8@3600MHz; MSI RTX2070 SUPER Ventus stock.

  kornel

Junior
Статус: Не в сети
Регистрация: 29.04.2017
Фото: 3
lameover писал(а):
некоторые отыскивают какие-то интересные способы, после которых у них вольтаж до 0.9 опускается и гигагерцы до 2.2

При сбалансированном плане эл.питания(не тот что от AMD, а стандартный от винды) проц начинает сбрасывать вольтаж и частоты, но при мало мальской нагрузке частоты подлетают ровно как и вольтаж.

_________________
AMD Ryzen 3900x, GTX 1080 GAMING, ASRock X470 Taichi, DDR4 Kingston KHX3600C17D4-8GX 2х8Gb

  vertik46

Junior
Статус: Не в сети
Регистрация: 30.03.2019
Откуда: Суджа
lameover писал(а):
Проблема реально была, и как я там где-то выше написал, решилась DDU и установкой последних дров. Видимо при переезде с интела на амд, что-то не очень взлетело.

У меня такое было, так же при переезде с интела на амд, вылечилось удалением через DDU и установкой новых дров, теперь бустит до 1950.
  gloom15

Member
Статус: Не в сети
Регистрация: 27.09.2016
Откуда: Владивосток
https://www.youtube.com/watch?v=CloyuBw_E_0
судя по видео - лучший режим работы памяти что-то около 3200CL16 :)

_________________
R7 7700x, Gigabyte B650m gaming x ax, 2*16Gb DDR5 Patriot Viper Venom PVV532G620C40K, Palit RTX4070Ti GameRock Classic

  antonshe

Member
Статус: Не в сети
Регистрация: 04.12.2010
Откуда: Днепр
plutonix писал(а):
Привет всем! Сегодня приехал мой 3600 BOX, пересобрал, запустил, Винду переактивировал, пока играю в новую машину) До игр ещё не дошёл)
Биос бесплатно перешивал заранее у продавца платы и памяти, сначала запустил "на минималках"- проц+плата+память+видюха, всё в дефолте, всё на авто- процессор 3,6, память 3200. Будем посмотреть в играх.

Можете сделать скрины аида с разгоном памяти. Собираюсь брать такой же комплект, память уже есть. Мать работает нормально с новым биос ?

_________________
AMD R5 1600,Asus TUF b450m pro gaming,Samsung 32gb 3200mhz,GA RTX3060 gaming,ssd Samsung 860evo 500gb,Chiftec APS550-B,DC Gammax 300,AOC I2481FXH.

  ma3uk

Member
Статус: Не в сети
Регистрация: 05.01.2018
gloom15 они там какую то чушь намерили, что 3200CL16 обгоняет 3600CL16 и 3200CL14(полный бред), судя по всему с вторичками в авто. Не стоит верить таким видео, где даже банально рабочие тайминги показать не могут.

_________________
1ПК - Intel i7 12700K@5.3GHz, MSI Z690 Egde DDR4, Patriot Viper 4400 32 Gb (4100Mhz), Asus Strix 3080Ti

  Spaik

Member
Статус: Не в сети
Регистрация: 23.06.2017
Откуда: Беларусь
Фото: 14
gloom15 писал(а):
судя по видео - лучший режим работы памяти что-то около 3200CL16

Лучший* режим работы памяти - это 3800cl14 с ужатыми таймингами в режиме 1:1.

_________________
Ryzen 7800x3d+Custom Loop/Asus ROG Strix B650E-F Gaming/2x32GB@6500cl30/Palit GameRock OmniBlack RTX 4080 16GB/CORSAIR RM850x

  lameover

Member
Статус: Не в сети
Регистрация: 31.01.2019
Откуда: Москва
Я в курсе что во вторник выйдет фикс для вольтажа и прочих хреней.
Но тут вроде уже отписывались люди как они побороли эту дичь. Я в поиск, похоже, не умею :(
Подскажите, пожалуйста!

_________________
Ryzen 7 3700x+AMD Prism; MSI X570 Gaming Plus; Ballistix(BLS2K8G4D30AESEK) 2x8@3600MHz; MSI RTX2070 SUPER Ventus stock.

  Agiliter

Advanced member
Статус: В сети
Регистрация: 29.03.2017
Руками зафиксировать и частоту и напряжение выключив буст.

_________________
https://docs.google.com/spreadsheets/d/1QpzbIzmoE3ntu6XvpchHspxqA0o6FPxc63_diTelzXw

  plutonix

Member
Статус: Не в сети
Регистрация: 25.06.2009
Откуда: Орёл
Фото: 133
antonshe писал(а):
Можете сделать скрины аида с разгоном памяти. Собираюсь брать такой же комплект, память уже есть. Мать работает нормально с новым биос ?
Я ничего не разгонял, по QVL выбрал из того, что в магазине было в наличии. По QVL она вроде как на 3400 работать может, но только собрал, еще не пробовал. В гарантийке, где предварительно БИОС перешивали, инженер пообещал, что всё заведется. Первый запуск- только процессор+плата+память+видюха, само перезагрузилось раза три- я чуть не обделался сначала, затем написало "new CPU is installed, press F1". В БИОСе всё дефолтное, ни процессор, ни память не крутил.
44078
