Ai Overclock Tuner [Manual]
BCLK Frequency [100.0000]
ASUS MultiCore Enhancement [Disabled]
SVID Behavior [Typical Scenario]
AVX Instruction Core Ratio Negative Offset [0]
CPU Core Ratio [Sync All Cores]
1-Core Ratio Limit [50]
2-Core Ratio Limit [50]
3-Core Ratio Limit [50]
4-Core Ratio Limit [50]
5-Core Ratio Limit [50]
6-Core Ratio Limit [50]
BCLK Frequency : DRAM Frequency Ratio [Auto]
DRAM Odd Ratio Mode [Enabled]
DRAM Frequency [Auto]
Xtreme Tweaking [Disabled]
TPU [Keep Current Settings]
CPU SVID Support [Auto]
CPU Core/Cache Current Limit Max. [255.00]
Ring Down Bin [Auto]
Min. CPU Cache Ratio [Auto]
Max CPU Cache Ratio [Auto]
BCLK Aware Adaptive Voltage [Auto]
CPU Core/Cache Voltage [Manual Mode]
- CPU Core Voltage Override [1.400]
DRAM Voltage [Auto]
CPU VCCIO Voltage [1.10000]
CPU System Agent Voltage [1.15000]
PLL Termination Voltage [Auto]
PCH Core Voltage [Auto]
CPU Standby Voltage [Auto]

Realtime Memory Timing [Disabled]
FCLK Frequency for Early Power On [Auto]
Initial BCLK Frequency [Auto]
BCLK Amplitude [Auto]
BCLK Slew Rate [Auto]
BCLK Spread Spectrum [Auto]
BCLK Frequency Slew Rate [Auto]
DRAM VTT Voltage [Auto]
VPPDDR Voltage [Auto]
DMI Voltage [Auto]
Core PLL Voltage [Auto]
Internal PLL Voltage [Auto]
GT PLL Voltage [Auto]
Ring PLL Voltage [Auto]
System Agent PLL Voltage [Auto]
Memory Controller PLL Voltage [Auto]
PLL Bandwidth [Auto]
Eventual DRAM Voltage [Auto]
Eventual CPU Standby Voltage [Auto]
Eventual PLL Termination Voltage [Auto]
Eventual DMI Voltage [Auto]

CPU Load-line Calibration [Level 6]
CPU Current Capability [140%]
CPU VRM Switching Frequency [Auto]
VRM Spread Spectrum [Auto]
CPU Power Duty Control [T.Probe]
CPU Power Phase Control [Auto]
CPU VRM Thermal Control [Auto]
DRAM Current Capability [100%]
DRAM Switching Frequency [Auto]
CPU Core/Cache Boot Voltage [Auto]
DMI Boot Voltage [Auto]
Core PLL Boot Voltage [Auto]
CPU System Agent Boot Voltage [Auto]
CPU VCCIO Boot Voltage [Auto]
PLL Termination Boot voltage [Auto]
CPU Standby Boot Voltage [Auto]

Intel(R) SpeedStep(tm) [Disabled]
Turbo Mode [Disabled]
IA AC Load Line [0.01]
IA DC Load Line [0.01]
Hyper-Threading [Enabled]
Thermal Monitor [Enabled]
Active Processor Cores [All]
Intel Virtualization Technology [Disabled]
Hardware Prefetcher [Enabled]
Adjacent Cache Line Prefetch [Enabled]
Boot performance mode [Auto]
SW Guard Extensions (SGX) [Software Controlled]
Tcc Offset Time Window [Auto]
Execute Disable Bit [Enabled]
SMM Code Access Check [Enabled]
SMM Use Delay Indication [Enabled]
SMM Use Block Indication [Enabled]
Intel(R) SpeedStep(tm) [Disabled]
Turbo Mode [Disabled]
CPU C-states [Disabled]
CFG Lock [Disabled]
Intel(R) Speed Shift Technology [Enabled]
